SYSTEM SPECIFICATIONS
Model number breakdown
AFS
Advanced
Fertigation
System
-
MB
B= Single
MB = Multi
Batch
INL = Inline
-
200
Tank size in
Gallons
(per tank)
-
48
Number of
Recipes
Included
-
32
Number of
Additional
Zones
-
R
Remote
Access
‍
-
C
Denotes
Custom
Layout
AFS
Advanced
Fertigation
System
-
MB
B= Single Batch
MB = Multi Batch
INL = Inline Injection
-
200
Tank size in
Gallons
(per tank)
-
48
Number of
Recipes
Included
-
32
Number of
Additional
Zones
-
R
Remote
Access
‍
-
C
Denotes
Custom
Layout
Description
Specification
Model Number Inline Injection
AFS-INL
Model Number 200 Gallon Single Batch
AFS-B200
Model Number 350 Gallon Single Batch
AFS-B350
Model Number 500 Gallon Single Batch
AFS-B500
Model Number 200 Gallon Multi Batch
AFS-MB200
Model Number 350 Gallon Multi Batch
AFS-MB350
Model Number 500 Gallon Multi Batch
AFS-MB500
Batch Capacity AFS-B200
200 Gallons Max
Batch Capacity AFS-B350
350 Gallons Max
Batch Capacity AFS-B500
500 Gallons Max
Batch Capacity AFS-MB200
400 Gallons Max
Batch Capacity AFS-MB350
700 Gallons Max
Batch Capacity AFS-MB500
1000 Gallons Max
Batch Capacity AFS-INL
N/A - No Tank
Frame Type
Powdercoated Steel
Dry Weight AFS-B200
1,925 lbs
Dry Weight AFS-B350
2,250 lbs
Dry Weight AFS-B500
TBD
Dry Weight AFS-MB200
2,400 lbs
Dry Weight AFS-MB350
2,688 lbs
Dry Weight AFS-MB500
TBD
Dry Weight AFS-INL
Main skid weight (with 6 pumps): 778 lbs, pump skid weight: 317 lbs.
Irrigation Output Connection AFS-B200
1" PVC Socket
Irrigation Output Connection AFS-B200
1" or 1-1/2" PVC Socket
Irrigation Output Connection AFS-B200
1" or 1-1/2" PVC Socket
Irrigation Output Connection AFS-B200
1" or 1-1/2" PVC Socket
Irrigation Output Connection AFS-B200
1" or 1-1/2" PVC Socket
Irrigation Output Connection AFS-INL
1" or 1-1/2" PVC Socket
Irrigation Outputs AFS Single Batch Units
12 outputs + dump (13 total)
Irrigation Outputs Custom Layout Units
Varies per customer. 13 max outputs including dump
Irrigation Outputs Multi-Batch Units
12 max outputs per tank (24 total) including dump
Irrigation Outputs Inline Units
Varies - 25 max outputs, including dump
Fresh Water Connection
1" PVC FNTP fitting
Fresh Water Connection (Inline)
1.5" PVC FNTP fitting
Waste (Dump) Output Connection AFS-B200
1" PVC Socket
Waste (Dump) Output Connection AFS-B350
1" or 1-1/2" PVC Socket
Waste (Dump) Output Connection AFS-B500
1" or 1-1/2" PVC Socket
Waste (Dump) Output Connection AFS-MB200
1" or 1-1/2" PVC Socket
Waste (Dump) Output Connection AFS-MB350
1" or 1-1/2" PVC Socket
Waste (Dump) Outputs Connection AFS-MB500
1" or 1-1/2" PVC Socket
Waste (Dump) Outputs Connection AFS-INL
1" or 1-1/2" PVC Socket
Outgoing Flow Rate
Varies per project, max 40 GPM
Incoming Flow Rate
Variable 5-50 GPM
Operating Pressure
Max 95 PSI
Temperature
Operational temperature: >32F / <100F
Irrigation Pumps
2HP or 3HP stainless steel multi-stage vertical
Click here to view full technical manual for pumps
Nutrient Dosing Pumps Sizing - Batch
1.1 GPH, 2.8 GPH, 6.4 GPH, 9.5 GPH
Nutrient Dosing Pumps Sizing - Inline
Grundfos SMART digital dosing pumps (up to 12) -2.5mL/hr – 2 GPH & 150mL/hr – 32 GPH available
Electrical (Single and Multi-Batch)
120/240VAC (w/ neutral) 40AMP
(Requires 60AMP local disconnect);
‍
Requires CAT5/6 cable connection to building internet for all remote and data connectivity
Electrical (Custom layouts)
Varies
Please consult Coordination Documents
Electrical (Inline)
Controller power required: 110/120VAC @ 20A dedicated circuit;
‍
Pump power options: Single phase 200-240VAC,3 phase 200-240VAC, 3 phase 440-480VAC(amperage varies by horsepower);
‍
System Upgrade Modules (remote control cabinets)require 20AMP 110/120VAC dedicated circuit(s);
‍
Requires CAT5/6 cable connection to building internet for all remote and data connectivity
UL & cUL Listing
UL508A rating on control cabinets
Description
Model Number Inline Injection System
Model Number 200 Gallon Single Batch
Model Number 350 Gallon Single Batch
Model Number 500 Gallon Single  Batch
Model Number 200 Gallon Multi-Batch
Model Number 350 Gallon Multi-Batch
Model Number 500 Gallon Multi-Batch
Batch Capacity AFS-B200
Batch Capacity AFS-B350
Batch Capacity AFS-B500
Batch Capacity AFS-MB200
Batch Capacity AFS-MB350
Batch Capacity AFS-MB500
Batch Capacity AFS-INL
Frame Type
Dry Weight AFS-B200
Dry Weight AFS-B350
Dry Weight AFS-B500
Dry Weight AFS-MB200
Dry Weight AFS-MB350
Dry Weight AFS-MB500
Dry Weight AFS-INL Skid
‍
Irrigation Output Connection AFS-B200
Irrigation Output Connection AFS-B350
Irrigation Output Connection AFS-B500
Irrigation Output Connection AFS-MB200
Irrigation Output Connection AFS-MB350
Irrigation Output Connection AFS-MB500
Irrigation Output Connection AFS-INL
Irrigation Outputs AFS Single Batch Units
Irrigation Outputs Custom Layout Units
Irrigation Outputs Multi-Batch Units
Irrigation Outputs Inline Skids
Fresh Water Connection
Fresh Water Connection (Inline)
Waste (Dump) Output Connection AFS-B200
Waste (Dump) Output Connection AFS-B350
Waste (Dump) Output Connection AFS-B500
Waste (Dump) Output Connection AFS-MB200
Waste (Dump) Output Connection AFS-MB350
Waste (Dump) Output Connection AFS-MB500
Waste (Dump) Output Connection AFS-INL
Outgoing Flow Rate
Incoming Flow Rate
Operating pressure
Temperature
Irrigation Pumps
‍
Nutrient Dosing Pumps Sizing - Batch
Nutrient Dosing Pumps Sizing - Inline

‍
Electrical - Single and Multi-Batch

‍
‍
Electrical - Inline







‍
‍
Electrical - Custom layouts
‍
UL and cUL Listing
Specification
AFS-INL
AFS-B200
AFS-B350
AFS-B500
AFS-MB200
AFS-MB350
AFS-MB500
200 Gallons Max
350 Gallons Max
500 Gallons Max
400 Gallons Max
700 Gallons Max
1000 Gallons Max
N/A - No tank
Powdercoated steel
1,925 lbs
2,250 lbs
TBD
2,400 lbs
2,688 lbs
TBD
Main skid weight (with 6 pumps): 778 lbs
Pump skid weight: 317 lbs
1" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
12 outputs + dump (13 total)
Varies, 13 max outputs including dump
12 max outputs per tank (24 total)
Varies, 25 max outputs including dump
1" PVC FNTP fitting
1.5" PVC FNTP fitting
1" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
1" or 1-1/2" PVC Socket
Varies per project, max 40 GPM
Variable 5-50 GPM
Max 95 PSI
Operational temperature: >32F / <100F
2HP or 3HP stainless steel multi-stage vertical
Click here to view full technical manual for pumps
1.1 GPH, 2.8 GPH, 6.4GPH, 9.5 GPH
Grundfos SMART digital dosing pumps (up to 12) -2.5mL/hr – 2 GPH & 150mL/hr – 32 GPH available
120/240VAC (w/ neutral) 40AMP
(Requires 60AMP local disconnect);
Requires CAT5/6 cable connection to building internet for all remote and data connectivity
Controller power required: 110/120VAC @ 20A dedicated circuit;
Pump power options: Single phase 200-240VAC,3 phase 200-240VAC, 3 phase 440-480VAC(amperage varies by horsepower);
System Upgrade Modules (remote control cabinets)require 20AMP 110/120VAC dedicated circuit(s);
Requires CAT5/6 cable connection to building internet for all remote and data connectivity
Varies
Please consult Coordination Documents
UL508A on control cabinets


System Specifications‍
For detailed specifications, please download the pdf version below.
AFS-INL Specifications
AFS-B200 Specifications
AFS-B350 Specifications
AFS-Multi-Batch Specifications
+
